New Refrigeration Air Conditioning Vacuum Pump + Flaring Tool + Gauge Manifold

You are purchasing a brand new, in box, absolute quality 3CFM single stage vacuum pump + off center pipe flaring tool + 2-way manifold/gauge.

Vacuum Pump Specifications

• Brand new in box

• 3 CFM of free air displacement

• Durable die cast aluminium housing
• Force feed lubrication system: Designed to provide clean filtered oil to all the internal bearings to help reduce maintenance
• 1/4 SAE
• A powerful 180Watt 1/4 HP motor
• Pump rotating speed: 1440 RPM
• Ultimate vacuum: 10   Pa
• Oil capacity: 200mL
• Oil anti-flow back design
• An oil window allowing for a quick visual check
• Power supply: 220V, 50Hz, 10Amp three pin Australian Standard electricity plug
• Sturdy plastic legs for super low vibration & noise
• A handle for easy handling
• Package Weight : 2Kg
• Package Dimensions: 32 cm(L) x 16 cm(W) x 28 cm(H)

Flaring Tool Specifications

• Brand new in box

• Heavy duty

• Suitable for R410A
• Off center (45 degree angle - for new refrigeration gases)
• Used by major HVAC, plumbing & automotive professionals
• Suits pipe sizes: 1/4", 5/16", 3/8", 1/2, 5/8", 3/4"

• Off center cone rotation
• Package Weight: 1.4KG
• Package Dimension: 20 cm(L) x 15 cm(W) x 10 cm(H)

Gauge Specifications

• Brand new in box

• Aluminum 2-way manifold
• Comes with 3 x 36" hoses for (R410A)

• Solid Aluminum body
• Stainless steel ball valve design

• Extra large sight glass for visual refrigerant check
• Dials graded in KPa, psi, C° & F°
• Dampened gauges smoothing out needle movement
• Can be easily re-calibrated in the field to maintain accuracy
• Hose labeled with Burst pressure & Max work pressure

• Burst Pressure: 4000 PSI

• Max work pressure: 800PSI
• Package dimensions: 28 cm (L) x 20cm (W) x 8cm (H)
• Package weight: 1.6Kg


• Package includes: The vacuum pump, 1 x 250mL oil bottle, detailed user manual, pipe flaring tool & 2-way gauge
