EVO-CONCEPT Pass-through Dishwasher - CO-142HRSBDD

EVO-CONCEPT pass-through dishwasher with drain pump and detergent dispenser

• Hourly production: 60 baskets/hour - 720 dishes/hour
• Clearance (max ware height): 440mm
• Wash cycles: 55-75-120 seconds
• Double rotating wash and rinse systems, made of AISI-304 stainless steel
• Water consumption: 2.4 litres/rinse
• Safety magnetic switch for hood opening
• Adjustable legs
• Supplied with 1 base basket; 1 plate basket and 2 cutlery containers
• WaterMark approved
• Hood type dishwasher - EVO Generation - Concept range.
• Hourly production: 60 baskets/hour - 720 dishes/hour
• Clearance (max ware height): 440mm
• Electronic control
• Wash cycles: 55-75-120 seconds
• Stainless steel
• Counterbalanced hood
• Double rotating wash and rinse systems, made of AISI-304 stainless steel
• Wash pump, 600W each
• Drain pump: 70W drainage cycle
• Tank with capacity: 33 litres
• Boiler heating power: 6kW
• Boiler capacity: 9 litres
• Water consumption: 2.4 litres/rinse
• Thermostatic temperature control: washing at 60°C and rinsing at 90°C
• Thermostop
• Safety thermostats
• Built-in automatic rinse dispenser and detergent doser
• Built-in non-return valve
• Safety magnetic switch for hood opening
• Adjustable legs
• Supplied with 1 base basket; 1 plate basket and 2 cutlery containers
• Watermark approved
• Can be converted to single phase
• 415V / 50Hz

1 Year Parts and Labour Warranty

Specifications
Net Weight (Kg) 126
Width (mm) 630
Depth (mm) 750
Height (mm)
Packing Width (mm) 905
Packing Depth (mm) 825
Packing Height (mm) 1720
Power adjustable: 11.1/3~N kW/A
